| Port Size: | DN50-300 | Standard or Nonstandard: | Standard |
|---|---|---|---|
| Structure: | Check | Pressure: | Low Pressure |
| Power: | Manual | Temperature of Media: | Medium Temperature |
| Material: | Cast iron/Ductile iron | Media: | Water,oil,gas,steam,etc |
| Design Standard: | DIN3352 | Test standard: | DIN3230 |
| Standard Range: | GB,BS,ANSI,JIS,DIN,etc | Flange: | DIN3202 F6 |
| Application: | Building industry,Power and Public utilities... |
1. Nominal diameter: DN40–DN400
2. Working pressure: PN10/16
3. Valve Design: BS5153,API594
4. Face-to-face: DIN 3202 F6,ASME B16.10
5. Flange Standard: EN1092-2 PN10/PN16
6. Test Standard: EN12266,API598
|
Nominal Diameter DN |
40-400 |
40-400 |
MM |
|
|
Nominal Pressure PN |
1.0 |
1.6 |
Mpa |
|
|
Test Pressure |
Shell |
1.5 |
2.4 |
|
|
Sealing |
1.1 |
1.76 |
||
|
Working Temperature |
-10~150 |
℃ |
||
|
Suitable Medium |
Water,Sewage,Sea Water,Air,Foodstuff,Oil etc. |
|||
Application
1. Water works and water resource project
2.Environment protection
3.public facilities
4.Power and Public utilities
5.Building industry
6.Petroleum, chemical
7.Steel, metallurgy
8.Paper making industry
Advantage
1. OEM Factory : Professional manufacturer, clients from whole world.
2. High Quality, Competitive Price: Custom is accepted.
3. Complete Service: Long service Life, Fast delivery, Multilingual services.
4. Certificates: ISO9001, CE, NSF, TS, WRAS.
5. Low MOQ: Ready for providing the sample and producing some small orders.
